ATS Automatic Transfer Switch 63A
An Automatic Transfer Switch (ATS) 63A is a crucial electrical device designed to automatically switch the power supply from a primary source (such as the utility/grid) to a secondary or backup source (such as a generator or solar inverter) when the primary power fails. Once the grid power returns to normal, the ATS automatically transfers the load back to it without manual intervention — ensuring continuous power to your appliances, systems, and critical equipment.
Built for use in residential, commercial, and industrial environments, this ATS is rated for 63 A (amps), making it suitable for medium-to-high load applications including homes, offices, factories, clinics, and data centers.
Product Details
| Model Name |
JJTP2-63A Auto Phase Selector / Intelligent Changeover Switch |
| Main Function |
Automatically selects the best available phase, protects against over/under voltage, overcurrent, fuse blow, overheating, and phase failure |
| Rated Working Voltage |
~220 VAC (Operating range: 220-300 V) |
| Over-voltage Protection |
Adjustable: 230-300 V (Default: 270 V) |
| Under-voltage Protection |
Adjustable: 140-210 V (Default: 170 V) |
| Recovery Time / Power-On Delay |
Adjustable: 1-500 seconds |
| Hysteresis |
Over & asymmetry: ~5 V; Under-voltage: ~3 V |
| Asymmetry Trip Delay |
~10 seconds |
| Phase Priority Setting |
User can set input phase order priority (e.g., ABC, ACB) |
| Display |
Digital LED display for voltage and current monitoring |
| Available Models |
63A and 100A versions available |
| Dimensions |
100 × 100 × 80 mm |
