Compared with lead-acid batteries:
Community discussions also note that 24V 200Ah LiFePO4 batteries are popular for solar backup because of their long cycle life and high usable capacity.
| Feature | Details |
|---|---|
| Model | MR-LBP24-200-WMT |
| Battery Type | LiFePO4 (Grade A Cells) |
| Nominal Voltage | 25.6V |
| Capacity | 200Ah |
| Energy Storage | 5.12kWh |
| Cycle Life | ≥6000 cycles |
| Design Life | ≥10 years |
| Max Charge Current | 120A |
| Max Discharge Current | 120A |
| Peak Current | 125A (2 sec) |
| Communication | RS485 / CAN / RS232 |
| Parallel Support | Up to 15 batteries |
| Display | 4.3″ Touch LCD |
| Mounting | Wall Mount |
| Weight | Approx. 44kg |
| Dimensions | 398 × 200 × 597 mm |
This battery is good for:
Typical supported loads:
Approximate backup with full charge:
| Load | Estimated Backup |
|---|---|
| 500W | 8–9 hours |
| 1000W | 4–5 hours |
| 2000W | 2–2.5 hours |
