Sako Sunon-Eco 8.2kW Hybrid Inverter

Sako Sunon-Eco 8.2kW Hybrid Inverter is a high-capacity hybrid solar inverter designed for residential, commercial, and small industrial solar power systems. It provides Sako Sunon-Eco 8.2kW Hybrid Inverter pure sine wave output, ensuring stable and safe electricity for sensitive devices such as computers, TVs, refrigerators, air conditioners, and office equipment.

This inverter intelligently integrates solar energy, grid power, and battery storage, delivering uninterrupted power even during outages. With a high-efficiency MPPT solar charge controller, it maximizes energy harvest from solar panels and improves overall system performance, reducing electricity costs.

The Sako Sunon-Eco 8.2kW Hybrid Inverter supports 48V battery systems, compatible with both lithium and lead-acid batteries, and can operate with or without batteries, offering flexible installation. Its LCD display allows real-time monitoring, and built-in protection features safeguard appliances from overload, short-circuit, and over-voltage conditions. Sako Sunon-Eco 8.2kW Hybrid Inverter Parallel operation support allows the system to scale for higher power needs.

• Rated AC Output Power: 8200W
• Battery Voltage: 48V
• General
  • 3-in-1 Function
    • MPPT Inverter
    • On Grid /Off Grid
    • Hybrid
  • Communication optional
    • USB / RS232 / RS485 / Dry-Contact / Wi-Fi
  • Dual MPPT tracker inside (2pcs x 18A)
  • Max PV input: 8000W
  • Real hybrid can feed into the grid
  • Works with & without battery
  • Parallel up to 6pcs optional
  • Smart battery management
    • Reserved communication port for BMS
  • Sako Sunon-Eco 8.2kW Hybrid Inverter
  • Can feed back to the grid
  • Built-in dual MPPT controller
  • Battery independent design
  • Built in 120A/160A MPPT controller
  • Built-in Smart BMS
  • High PV input range (90~450VDC)
  • Dual AC Output
  • Waveform Pure sine wave
  • Touchable LCD screen
• Technical Information
  • Grid-Tie Operation PV Input (DC)
    • Nominal DC Volt/Max DC Voltage: 360VDC/450VDC
    • Start-up Voltage/Initial Feeding Voltage: 80VDC 120VDC
    • MPPT Voltage Range: 90-450VDC
    •  Input Current: 27A  x 2(MAX 40A)
    • Max. PV Input Power: 12000W(6000W x 2) 12000W(5500W x 2)
  • Grid Output (AC)
    • Nominal Output Volt: 220Vac/230Vac/240Vac, Single Phase
    • Output Voltage Range: 184V-265Vac or 195-253V (Selectable)
    • Nominal Output Current: 40A (Max. 2nd Output Current) 47.8A
    • Power Factor: 0.9
  • Efficiency
    • (DC to AC) 93 %
    • Max. Conversion Efficiency (DC/AC) 96 percent
  • Off-Grid Operation
    • AC Input (AC)
      • AC Start-up Voltage/Auto Restart Volt: 120Vac-140Vac/180Vac
      • Acceptable Input Voltage Range: 90-280Vac or 170-280Vac
      • Max. AC Input Current: 60A 60A
  • Battery Mode Output (AC)
    • Nominal Output Volt: 220Vac/230Vac/240Vac
