| Battery Chemistry | Lithium-iron phosphate (LiFePO₄) |
| Battery Capacity | 16kWh |
| Battery Cell Lifespan | 11,000 cycles (@25°C, 100% DOD, 0.5P, 70% SOH) |
| Product Lifespan | >8000 cycles (@20–25°C, 100A, 90% DOD) |
| Rated Voltage | 51.2V DC |
| Discharge Voltage Range | 43.2V – 56.8V DC |
| Charge Voltage Range | 43.2V – 56.8V DC |
| Recommended Charge/Discharge Current | 100A |
| Maximum Charge/Discharge Current | 200A |
| Depth of Discharge (DoD) | 90% |
| Charge Mode | CC – CV |
| Charge/Discharge Port | M8 Bolt |
| Communication Ports | CAN / RS485 / RS232 / WiFi / Bluetooth (Optional) |
| Display | Yes, LCD Touchscreen |
| Scalability | Up to 16 batteries (Max 256kWh) |
| Compatible Inverter Brands | Hithium, Victron Energy, Deye, Voltronic, SMA, GoodWe, Growatt, etc. |
| IP Rating | IP30 |
| Operating Temperature | Charging: 0°C ~ 40°C Discharging: -20°C ~ 40°C |
| Storage Temperature | -20°C ~ 60°C |
| Protection | Over-temperature, Under-voltage, Over-charge, Over-current, Short-circuit, Reverse connection, Fault protection |
| Humidity | 10% – 90% RH |
| Operating Altitude | ≤3000m |
| Cooling System | Natural cooling |
| Dimensions (mm) | Without box: 540.6 × 240 × 781.2 With box: 600 × 320 × 1120 |
| Weight | Net: 110kg Gross: 135kg (with wooden box) |
| Wheels | 4 Wheels |
| Certification | UN38.3 / MSDS / IEC62619 |
