Rated Output Power: 5 000 W / VA — power factor 1.0

Surge/Peak Output: ~10 000 VA

Battery Input Voltage: 48 V DC

AC Output: 230 VAC (±5%), 50/60 Hz auto-sensing

Transfer Time: 10 ms (UPS/PC mode), 20 ms (appliance mode)

MPPT Solar Charger:

• Supports up to 5 500–6 000 W PV power

• MPPT voltage range 120–430 V DC; max open-circuit voltage 450 V DC

• Max solar charge current: 100 A; efficiency ~97%

AC Battery Charger: Up to 80 A, 230 VAC input

Parallel Capability: Stack up to 6 inverters for greater power

Efficiency: Peak ~93% (in inverter mode)

Standby Load: Approx. 60–70 W

Form Factor & Weight: ~12 kg

Operating Conditions: 0–55 °C ambient; storage –15 to 60 °C; 5–95% RH (non-condensing)

Waveform: High-frequency pure sine-wave

Connectivity: CAN/RS485 for BMS, USB, optional Wi‑Fi/GPRS monitoring

Warranty: Standard 2‑year manufacturer warranty
