Rated Power: 3200VA/3000W

• Voltage: 230VAC
• Selectable Voltage Range
  • UPS: 170-280VAC
  • Appliances: 90-280VAC
• Frequency Range: 50Hz/60Hz(Auto Sensing)

• AC Voltage Regulation (Batt.Model): 230VAC +-5%
• Surge Power: 3200VA
• Power Factor: 0.8
• Efficiency (Peak): 90%
• Transfer Time
  • UPS: 10ms
  • Appliances: 20ms
• Wave Form: Pure Sine Wave
• No Load Current: 1.0A

• Battery Voltage: 12VDC
• Low Battery Alarming Voltage: 11VDC
• Low Battery Cut Off Protection Voltage: 10.5VDC
• Low Battery Recovery Voltage: 11.5VDC
• Floating Charge Voltage: 13.5VDC
• Overcharge Protection: 16VDC
• Smart battery protection

• Maximum PV Array Power: 3500W
• MPPT Range Operation Vol: 30-450VDC
• Best PV range: 120-400VDC
• Maximum PV Array Open Circuit Vol.: 400VDC
• Number of MPPT trackers / Max output current: 80A
• Maximum AC Charge Current: 60A
• Maximum Efficiency: 98%

• RS232 / GPRS / Optional WIFI

• Dimension D x W x H: 400 x 306 x 103mm
• Net Weight: 5.4 Kg
• Gross Weight: 6.1 Kg

• Humidity: 5% to 95% Relative Humidity (Non-condensing)
• Operation Temperature: -10°C-50°C
