Original price was: 680,000৳ .550,000৳ Current price is: 550,000৳ .
| Models | 100K | 110K |
| Input DC | ||
| Max. input voltage | 1100 V | |
| Rated voltage | 600 V | |
| Start-up voltage | 195 V | |
| MPPT voltage range | 180 – 1000 V | |
| Max. input current | 10 × 32 A | |
| Max. short circuit current | 10 × 40 A | |
| MPPT number / Max. input strings number | 10 / 20 | |
| Output AC | ||
| Rated output power | 100 kW | 110 kW |
| Max. apparent output power | 110 kVA | 121 kVA |
| Max. output power | 110 kW | 121 kW |
| Rated grid voltage | 3/N/PE, 220 V / 380 V, 230 V / 400 V | |
| Rated grid frequency | 50 Hz / 60 Hz | |
| Rated grid output current | 152.0 A / 144.3 A | 167.1 A / 158.8 A |
| Max. output current | 167.1 A | 183.8 A |
| Power factor | > 0.99 (0.8 leading – 0.8 lagging) | |
| THDi | < 3% | |
| Efficiency | ||
| Max. efficiency | 98.7% | |
| EU efficiency | 98.3% | |
| Protection | ||
| DC reverse-polarity protection | Yes | |
| Short circuit protection | Yes | |
| Output over current protection | Yes | |
| Surge protection | DC Type II / AC Type II (AC Type I optional) | |
| Grid monitoring | Yes | |
| Anti-islanding protection | Yes | |
| Temperature protection | Yes | |
| Strings monitoring | Yes | |
| I/V Curve scanning | Yes | |
| Integrated AFCI 2.0 | Optional | |
| Integrated PID recovery | Optional | |
| Integrated DC switch | Yes | |
| Integrated AC switch | Optional | |
| General Data | ||
| Dimensions (W × H × D) | 1065 × 567 × 344.5 mm | |
| Weight | 91 kg | |
| Topology | Transformerless | |
| Self-consumption (night) | < 2 W | |
| Operating ambient temperature range | -30 ~ +60°C | |
| Relative humidity | 0 – 100% | |
| Ingress protection | IP66 | |
| Cooling concept | Intelligent fan-cooling | |
| Max. operation altitude | 4000 m | |
| Grid connection standard | VDE-AR-N 4105, VDE-AR-N 4110, VDE V 0124, VDE V 0126-1-1, UTE C15-712-1, NRS 097-1-2, G98, G99, EN 50549-1/-2, RD 1699, TOR, UNE 206006, UNE 206007-1, CEI 0-21, IEC61727, DEWA | |
| Safety / EMC standard | IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4 | |
| Features | ||
| DC connection | MC4 connector | |
| AC connection | OT terminal (max. 185 mm²) | |
| Display | LCD | |
| Communication | RS485, Optional: Wi-Fi, GPRS, PLC | |
