Original price was: 45,000৳ .36,000৳ Current price is: 36,000৳ .
| Technical Specification | REVO VM II PRO series | |||
| Rated Power | 1600VA/1600W | 3200VA/3200W | 4000VA/4000W | 6000VA/6000W |
| AC INPUT | ||||
| AC Voltage | 230VAC | |||
| Voltage Range | 170-280VAC（For Personal Computers）；90-280 VAC（For Home Appliances） | |||
| Frequency Range | 50/60Hz（Auto sensing） | |||
| AC OUTPUT | ||||
| Surge Power | 3200VA | 6400VA | 8000VA | 12000VA |
| AC Voltage Regulation (Battery Mode) | 230VAC ± 5% | |||
| Rated frequency | 50/60Hz | |||
| Efficiency (Peak) | 93% | |||
| Transfer Time | 10ms（For Personal Computers）；20ms（For Home Appliances） | |||
| BATTERY | ||||
| Battery Voltage | 12VDC | 24VDC | 48VDC | |
| Floating Charge Voltage | 13.5VDC | 27VDC | 54VDC | |
| Overcharge Protection | 16VDC | 33VDC | 63VDC | |
| Battery type | Lithium/Lead-acid | |||
| SOLAR CHARGER & AC CHARGER | ||||
| Maximum PV Array Open Voltage(V) | 500VDC | |||
| Maximum PV Array Power | 2000W | 3500W | 5000W | 7000W |
| MPPT voltage range(V) | 30~450VDC | 60~450VDC | ||
| Maximum input current | 15A | 27A | ||
| MPPT tracker/strings | 1 | |||
| Maximum solar charge current | 80A | 120A | ||
| Maximum AC charge current | 60A | 100A | ||
| Maximum charge current | 80A | 120A | ||
| PROTECTION & FEATURE | ||||
| AC overcurrent | Yes | |||
| AC overvoltage | Yes | |||
| Over temperature protection | Yes | |||
| Smafi load management | NO | Yes(optional) | ||
| On Grid | Yes (optional) | |||
| GENERAL PARAMETERS | ||||
| Operation temperature | -10°C ~ 50°C | |||
| Relative humidity | 5% ~ 95% (Non-condensing) | |||
| Altitude | (2000m Derating) | |||
| Dimensions DxWxH(mm) | 348*270*95 | 400*300*115 | ||
| Net Weight(KG) | 5 | 5.5 | 8.5 | 9 |
| COMMUNICATION | ||||
| Interface | Standard:RS232,USB; CAN&RS485; Optional:WiFi,Bluetooth | |||
| Safety standard | EN/IEC62109-1,EN/IEC62109-2 | |||
