Original price was: 145,000৳ .110,000৳ Current price is: 110,000৳ .
| Technical Specification | REVO VM IV series | ||||
| Rated Power(W) | 4000VA/4000W | 6000VA/6000W | 6000VA/6000W | 8000VA/8000W | 11000VA/11000W |
| AC INPUT | |||||
| Nominal Voltage(VAC) | 230VAC | ||||
| Voltage range(VAC) | 170~280VAC / 90~280VAC | ||||
| Frequency range(Hz) | 50/60Hz | ||||
| AC OUTPUT | |||||
| Surge power | 8000 | 12000 | 16000 | 22000 | |
| Output voltage(VAC) | 220/230/240 | ||||
| Output wave form | Pure sine wave | ||||
| Rated Frequency(Hz) | 50/60 | ||||
| Efficiency | 93% max | ||||
| Transfer time | 10ms typical(narrow range);20ms typical (wide range) | ||||
| BATTERY | |||||
| Nominal DC voltage(VDC) | 24 | 48 | |||
| Floating charge voltage(VDC) | 27 | 54 | |||
| Overcharge protection(VDC) | 31 | 63 | |||
| Battery type | Lithium & Lead-acid | ||||
| SOLAR CHARGER & AC CHARGER | |||||
| Max.PV array open circuit voltage(VDC) | 500 | ||||
| Max.PV array power(W) | 5000W | 7000W | 8000W（4000*2） | 11000W(5500*2) | 11000W(5500*2) |
| MPPT input voltage range@operating(VDC) | 60-450 | ||||
| Max.input current(A) | 27 | 15*2 | 27*2(Max 40A） | ||
| Max.solar charging current(A) | 120 | 120 | 150 | ||
| Max.AC charging current(A) | 100 | 120 | 150 | ||
| Max.charging current(A) | 120 | 120 | 150 | ||
| DISPLAY INTERFACE | |||||
| Parallel function | up to 6 units | ||||
| Communication | Standard:RS232,CAN&RS485;Optional:WiFi,Bluetooth | ||||
| Display | 5”colorful LCD | ||||
| ENVIRONMENT | |||||
| Humidity | 5~90%RH (No Condensing) | ||||
| Operating Temperature | -10°C to 50°C | ||||
| Net Weight(KG) | 9 | 10 | 18 | 18.8 | 20 |
| Dimensions D x W x H(mm) | 434*311*126.5 | 500*440*136 | 420*561.6*152.4 | ||
