| System rating (Name Plate) |
VA |
900/ 750w |
| Input current at no load at Nominal Battery voltage |
Adc |
2.6 |
| Full Load Input Current ±2A |
Amp |
60 |
| Operating DC voltage |
V |
12 |
| Nominal Output voltage in inverter mode |
Vac |
220V ± 7V |
| Nominal Output Frequency of Inverter |
Hz |
50 ± 1 HZ |
| Output voltage regulation |
% |
180-220 |
| Overload capacity |
Sec |
6 Retry |
| Cooling Fan ON at temp |
OC |
60 (or >50% of Rated Load or >8A) |
| Cooling Fan Off at temp |
OC |
55 (or <40% of Rated Load or <5A Charging) |
| Battery low voltage alarm per battery |
Vdc |
10.8 /10.5± 0.2 (11.5-default for LiFePo4 batt) |
| Battery low voltage cut per battery |
Vdc |
10.5 /10.2± 0.2 (With 4 Retry) (11.0-default for LiFePo4 batt) |
| Max Battery charging voltage by grid per battery |
Vdc |
14.4 ± 0.2 |
| satiable for Tub-14.4V/28.8V,FALT-14.2V/28.4V,SMF-14.2V/28.4,GEL-14.2V/28.4V, LiFePo4-14.0V/28.0V |
| satiable for Tub-13.8V/27.6V,FLAT-13.6V/27.2V,SMF-13.8V/27.6,GEL-13.8V/27.6V, LiFePo4-Maintain Boost With Trickle Charging |
| Max Battery charging current by grid in Hi/Lo option |
Adc |
16/12 ±2A |
| satiable for Tub-12/16A,FLAT-10/14A, SMF-10/14A,Gel-10/16A, LiFePo4-12/16 |
| Grid low cut voltage (IT load/Normal load) |
Vac |
180/100 ± 10 |
| Grid low cut voltage recovery (IT load/Normal load) |
Vac |
190/100 ± 10 |
| Grid high cut voltage (IT load/Normal load) |
Vac |
265/280 ± 10 |
| Grid high cut voltage recovery (IT load/Normal load) |
Vac |
255/270 ± 10 |
| Grid charging Enable/Disable |
Yes |
| Selection of UPS Load/Normal Load |
Yes |
| Protections |
Overload, Battery Deep discharge, Battery Overcharge, Short circuit(1retry),Battery Hi, Over Temp, Fuse/MCB Trip, battery reverse |
| LCD Display parameters |
Product, UPS ON/OFF, Mains Status, Mains voltage, Mains Frequency. Output Voltage, output frequency, Battery Voltage, Load percentage, Charging Status, Charging Mode ,Battery Mode, UPS Mode ON/OFF,Grid Charge ON/Off,Inv Type, over load, short circuit, battery low, over temp, Fuse/MCB trip, Battery high |
